Quick-clamping puller ∙ 2-arm
Length: 227 mm
Product information
- Application:
Inner and outer puller - Quick adjustment thanks to “one-nut” fixation per arm
- Quick and easy installation
- Forged arms
- High strength and rigidity for safe work
- Solid all-steel bridge
Variants
Technical Data
| Arm length (la) | 160 mm |
| Hook deflection (ah) | 28 mm |
| Height of tip (hs) | 4 mm |
| Arm deflection (aa) | 38 mm |
| Hook foot width (bh) | 26 mm |
| Hook foot depth (th) | 17 mm |
| Hook foot thickness at tip (sh) | 11.5 mm |
| Clamping range | 185 mm |
| Max. tonne | 10 |
| Clamping depth (mm) | 160 |
| Spindle | M20x1,5x248 |
