9 x 12 mm Torque wrench ∙ 2 – 10 Nm ∙ ±2%

Name: 9 x 12 mm Torque wrench ∙ 2 – 10 Nm ∙ ±2%
Brand: HAZET
SKU: 6280-1CT
Price: 347.72 EUR
Availability: InStock

Length: 181 mm ∙ Torque range : 2 – 10 Nm ∙ Accuracy: 2 % ∙ 9 x 12 mm insert square ∙ hollow

Item number

6280-1CT

4000896026005

Variants

Product information

Plug connection for holding insert tools
Accuracy ± 2 % of the scale value (in the direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool
Safe:
- Haptic (close-gap release)
- Audible ("click" sound)
With calibration certificate and serial number
Especially slim design thanks to spring-loaded puller sleeve for locking the setting values
Safe and fast adjustment of the desired torque value by turning the handle
Made in Germany
No more turning back: Continuous long-term tests on the 5000 series and 6000 series of HAZET torque wrenches have demonstrated that turning them back to the smallest scale value is not required

SYSTEM 6200-1 CT insert torque wrench ∙ 2 – 500 Nm ∙ with insert square ∙ accuracy ± 2 / 4 %

Output	9 x 12 mm insert square, hollow
Tolerance	2 %
Tightening torque minimum	2 Nm
Head Width b	22 mm
Tightening torque maximum	10 Nm
Head Thickness a	17 mm
Scale Graduation (Nm)	0.2 Nm
Standard	DIN EN ISO 6789-2:2017
Inside micrometre of the adjusting tool l2	19.5 mm
Length	181 mm
Actuating force min.-max. kg	1.3 – 6.6
Effective torque wrench length I1 mm	141 mm
