Product information
- Operation of screw connections in areas with restricted access, ratchet function enables continuous working
- Long, slim design
- Shank with sturdy HAZET double-T-profile
- Box-end wrench with reversible ratchet
- Fine-tooth, 72 teeth ∙ Operating angle 5°
Ä 8 and 9 mm: 60 teeth ∙ Operating angle 6° - Box-end side 13° offset
Variants
Technical Data
| Wrench size | 19 mm |
| Output |
|
| Surface |
|
| mouth position | 15 ° |
| Length | 268.3 mm |
| Head thickness (a1) | 11.5 mm |
| Head thickness (a2) | 9.1 mm |
| Head Width (b1) | 34.1 mm |
| Head Width (b2) | 39.7 mm |
