Product information
- Application:
Regulation of the control valve at the gas tank of VW Up! and Caddy model years 2012 → (adjustment is necessary after installation or removal) - Extra short construction for areas with restricted access
- Plug connection to hold insert tools
- Accuracy ± 4 % of the scale value (in direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool - Safety:
- Haptic (close-gap release)
- Audible (“click” sound)
- With calibration certificate and serial number
- Easy and safe adjustment of the desired torque value by turning the handle
- Made in Germany
- No more turning back: Continuous long-term tests on the 5000 series and 6000 series of HAZET torque wrenches have demonstrated that turning them back to the smallest scale value is not required
SYSTEM 6200-1 CT Insert torque wrenches
2 – 500 Nm ∙ with insert square ∙ accuracy ± 2 / 4 %
Variants
Technical Data
Output |
|
Tolerance | 4 % |
Tightening torque min Nm | 5 Nm |
Head Width b | 22 mm |
Tightening torque max Nm | 13 Nm |
Head Thickness a | 17 mm |
Scale Graduation (Nm) | 0.2 Nm |
Standard |
|
Inside micrometre of the adjusting tool l2 | 17.5 mm |
Length | 125.4 mm |
Actuating force min.-max. kg | 4.4 – 11.8 |
Effective torque wrench length I1 mm | 99 mm |
