Compressed air reducer


Product information

  • Application:
    Reduction of working pressure to protect high-quality pneumatic equipment
  • Inline pressure regulator for integration in the compressed air line or direct connection to motorised pneumatic equipment
  • Max. inlet pressure: 10 bar
  • Outlet pressure 6.3 bar
  • Max. air flow: 1300 l/min
  • Weight including air connection nipple: 140 g
  • Including:
    • Adapter from outside thread (OT) 14″ (12.91 mm) to outside thread (OT) 14″ (12.91 mm) for connecting to the device
    • Air connection nipple 7.2 Type 1 for connection to compressed air coupling
  • For safe operation on compressed air lines to 10 bar



Technical Data

Air connection outlet
  • Inside thread 12.91 mm (1/4″)
Air connection inlet
  • Inside thread 12.91 mm (1/4″)



safety instructions

show pdf
