Work bench ∙ mobile i 179NW ∙ single
L x W x H: 1150 x 600 x 964 mm ∙ 7 Drawers total
Product information
- More storage space than preceding model
- 6 flat drawers, loading capacity 30 kg, 81 mm high
1 high heavy-duty drawer, loading capacity 40 kg, 166 mm high - 30 mm wood multiplex birch work surface, oiled, replaceable
- Including nine-fold adjustable intermediary tray and fixed mounted door
- Cable aperture on rear panel allows, for example battery-powered devices to be charged when the door is locked
- Complete welded construction of the entire body for tough daily workshop use
- Additional square perforation for tool holder, e.g. HAZET 112-230
- Optimised, yielding edge protection on all four corners with real impact protection thanks to internal damping concept
- Flexible vice assembly (front, right, left) e.g. HAZET 2175Nas per drilling templates
- Chassis:
- Large wheels with high loading capacity (⌀ 125 mm) with precision ball-bearing and dual ball race in the swivel bearing, easy manoeuvrability even under high dynamic load
- 2 swivel castors with dual brake:
- Braked castors prevent rolling away
- Braked swivel bearings prevent the swivel castors from turning, e.g. on inclined surfaces
- Protective ring prevents dirt and threads from getting in
- Elastic castors enable smooth movement
- Locking concept:
- Mutual drawer locking for minimum tilting risk
- Lock located in the centre (central locking and cylinder lock) closes the door and drawers at the same time
- Only one key for locking the door and drawers at the same time (Included in delivery: 2 keys)
- 180° rotation, prevents the key from breaking off
- 100 % sliding-out with ball-bearing telescopic rails – self-closing
- Lockable storage compartment with 2 storage surfaces
- 2 storage spaces in the storage compartment, top: 15 kg / bottom: 35 kg
- Made in Germany
Variants
Technical Data
| Drawers, high | 1 x 166 x 522 x 398 mm |
| Drawers, flat | 6 x 81 x 522 x 398 mm |
| Drawers total | 7 |
| (Drawer) size for plastic drawer insert |
|
| Drawer dimensions | 522 x 398 |
| Drawer sliding-out % |
|
| Drawer guide |
|
| Drawer locking |
|
| Drawer lock |
|
| Worktop |
|
| Tool trolley impact protection |
|
| Loading capacity (static) | 1000 kg |
| Total loading capacity (dynamic) | 750 kg |
| Dimension | 1150 x 600 x 964 mm |
| Number of swivel castors | 2 |
| Diameter of swivel castors | 125 mm |
| Number of fixed castors | 2 |
| Diameter of fixed castors | 125 mm |
| Number of castors with brake | 2 |
| Colour |
|
