Product information
- Factory preset triggering value as requested
- Accuracy ± 2% (6391-10: 6%) of the preset value (in direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool - Plug connection, for holding insert tools
- Permanently adjustable value
- Especially suitable for application in industrial series fabrication
- Adjusting the desired torque value with adjustment wrench 6399 in conjunction with HAZET torque tester 7901E ∙ 7902E ∙ 7903E or another suitable device
- All wrenches of this series (HAZET 6391-6392) are without an adjusting scale
- With calibration certificate and serial number
- Made in Germany
Variants
Technical Data
Design ∙ Special feature |
|
Output |
|
Tolerance | 2 % |
Tightening torque minimum | 5 Nm |
Head Width b | 22 mm |
Tightening torque maximum | 50 Nm |
Head Thickness a | 17 mm |
Standard |
|
Length | 241 mm |
Actuating force min.-max. kg | 2.2 – 22.1 |
Effective torque wrench length I1 mm | 201 mm |
