Tool trolley i
L x W x H: 777 x 490 x 1035 mm ∙ 8 Drawers total
1. Manufacturer's recommended list price, dealer prices may vary – prices are subject to change and errors excepted.
1. Non-binding recommended promotional price from the manufacturer as part of the “Special Worldwide” campaign, for example, dealer prices may vary - prices subject to change and errors.
in stock
available again soon
out of stock
Product information
- Application:
Efficient, mobile organisation of tools - Tool trolley
- 7 flat drawers and 1 high drawer
- High flexibility: Handle and castors can be mounted either on the left or right
Work surfaces
- Work surface made of rugged steel sheet construction, powder-coated, plastic corner caps
- Fully sealed work surface protects inside of trolley from leaking liquids
- Work surface border strip prevents parts from falling down
Body / pull-handle
- Extremely rugged design
- Complete welded construction of the entire body for tough daily workshop use
- Bevelled edges prevent damage
- Commercially available rectangular perforation on the side panels offer fastening options for accessories
- For example, HAZET tool hooks for the article group 112
- For attached parts, such as can holder, holder for paper reel, paper bin, cable drum, etc.
- Rear screw points for mounting additional accessories
- Sturdy handle can be firmly mounted on both sides of the body
Locking concept
- 2-stage locking
- Central locking, lockable with cylinder lock and two keys
- Mutual drawer locking for minimum tilting risk
Drawer concept
- Self-closing and reciprocal locking of the drawers prevents unwanted opening
- 100% sliding-out with ball-bearing telescopic slides
- Disconnectable telescopic rail
Chassis
- Large wheels with high loading capacity with precision ball-bearing and dual ball race in the swivel bearing – easy manoeuvrability, even with high dynamic load, 2 guide rolls with dual brake:
- two baked castors prevent rolling away
- Braked swivel bearings prevent the swivel castors from turning, e.g. on inclined surfaces
- Protective ring prevents dirt and threads from getting in
- "Non-marking" castors leave no marks on the floor and enable smooth running
- Made in Germany
Assistent 175 – the new dimension
- Drawer area/volume: + approx. 24 % compared to 177 / 176N → area 24 % / volume 22 %
- Bearing load per drawer: + 50 % compared to 177 / 176N → 30 kg instead of 20 kg
- Improved rail technology: → ball-bearing telescopic rails instead of roller guides
- With new insert format: 3/3L+ (569 x 398 mm)
- And all with the same space requirement
Variants
Technical Data
| Drawers, high | 1× 164 x 569 x 398 mm |
| Drawers, flat | 7× 79 x 569 x 398 mm |
| Drawers total | 8 |
| Loading capacity per drawer | 30 kg |
| (Drawer) size for plastic drawer insert |
|
| Drawer dimensions | 569 x 398 mm |
| Drawer sliding-out % |
|
| Drawer guide |
|
| Drawer locking |
|
| Drawer lock |
|
| Worktop |
|
| Total loading capacity (dynamic) | 480 kg |
| Dimension | 777 x 490 x 1035 mm |
| Number of swivel castors | 2 |
| Diameter of swivel castors | 125 mm |
| Number of fixed castors | 2 |
| Diameter of fixed castors | 125 mm |
| Number of castors with brake | 2 |
| Colour |
|
