Hose reel ∙ open ∙ 20 m ∙ 13 mm inner ⌀
20 m
1. Manufacturer's recommended list price, dealer prices may vary – prices are subject to change and errors excepted.
1. Non-binding recommended promotional price from the manufacturer as part of the “Special Worldwide” campaign, for example, dealer prices may vary - prices subject to change and errors.
in stock
available again soon
out of stock
Product information
- Application:
Automatic hose reel offers tidiness in the workshop – hose not left lying around, thus reducing the risk of accidents - Robust steel design with roller guide
- Hose, inside ⌀: 13 mm (1/2″)
- Solid metal design
- Net weight of swivelling base: 3.4 kg
- Net weight including swivelling base: 21.6 kg
- Drilling distance for mounting bracket: width 145 mm / height 195 mm
- Dimensions: 445 x 201 x 434 mm
- To be used with HAZET safety coupling 9000-062
- For compressed air
- End stop
- Spring return with ratchet locking holders
- Hybrid polymer hose ∙ black
- Integrated roller inlet
- Swivel base – swivel range: 180°
- Open design against accumulation of dirt
- Visual inspection of the hose
- Length of connection hose: 2 m
- Installation via metal bracket or swivel base (included)
- Drill template on cardboard packaging for easy installation
Variants
Technical Data
| Air connection outlet |
|
| Air connection inlet |
|
| Thread type air inlet |
|
| Hose length | 20 m |
| Inside diameter of the hose | 13 mm |
| Dimension | 445 x 201 x 434 mm |
| Operating temperature range | -40°C – 60°C |
| Net weight | 18.2 kg |
| Length | 445 mm |
