Cordless drill ∙ 65 Nm

• Cordless drill ∙ 18 Volt
• Basic unit ∙ without battery ∙ without charger
• Compact, powerful drill with extremely short head length
• Quick-action drill chuck ∙ metal design ∙ auto-lock function
• Drill diameter: 1.5 – 13 mm
• Electronic emergency brake
• Forward/reverse with switch-on lock
• Ergonomic non-slip, rubberised grip
• LED light with persistence afterglow
• Belt clip and drill bit storage
• Number of torque levels: 18 + 1
• Tightening torque maximum
  • Hard: 65 Nm
  • Soft: 35 Nm
• Idle speed
  • Speed 1: 0 – 500 revolutions per minute
  • Speed 2: 0 – 1800 revolutions per minute
• LED battery capacity display on battery pack
• Compatible with all 18 V battery packs in the 9500 system
• Weight (without battery): 1.14 kg
• Brushless DC motor (BLDC):
  • Longer service life, less wear, no need to change the carbon brushes
  • High efficiency and hence lower battery consumption – more compact motor enables smaller installation dimensions
• Electronic Management System (EMS) protects the machine, extends service life and increases efficiency
• Max. storage temperature: 50° C
• Metal design with thrust ring

Do you know – Li-Ion batteries:

• Do not have any memory effect
• Consist of cells with 3.6 V each
• After full charge they have a higher voltage than 3.6 V i.e. 5 cells each 3.6 V = 18 V – but after full charge a peak voltage of up to 20 V is possible
  Attention: For a longer lifetime of the battery please store it charged up to 50 to 80 % only
• Have an energy density which is twice as high as nickel cadmium batteries, for example
• Have a nominal voltage three times higher than a nickel metal hydride battery
• Require multiple complete charging cycles to reach full capacity
