Cordless impact drill

• Application:
  Drilling / impact drilling
• Powerful machine with additional side handle
• Electronic Management System (EMS) protects the machine, extends service life and increases efficiency
• Anti-kickback shuts down the engine when blocked and prevents the wrist from twisting
• Turbo mode for faster and more powerful work. Switching on the turbo boost achieves up to 27% higher speed
• Maximum torque of 158 Nm for drilling, impact drilling and screwdriving, even in extreme applications. The selected torque setting is retained when switching from the drilling to the impact drilling function thanks to direct switching
• Brushless DC motor (BLDC):
  • Longer service life, less wear, no need to change the carbon brushes
  • Greater efficiency and thus less battery consumption – More compact motor allows for smaller installation dimensions
• Forward/reverse with switch-on lock
• Electronic emergency brake
• Robust die-cast aluminium gearbox housing
• Quick-action drill chuck in metal design with thrust ring and auto-lock function
• User protection even at maximum torque thanks to extendable handle
• Ergonomically designed, non-slip, rubberised handle
• Integrated LED light with persistence afterglow
• LED battery capacity display
• Includes mountable auxiliary handle, belt clip and bit storage
• Delivery does not include rechargeable battery and charger
• Compatible with all 18 V battery packs in the 9500 system
• Sound pressure level LpA: 93 dB(A)
• Sound power level LWA: 104 dB(A)
• Uncertainty: K=3 dB (A)
• Vibration acceleration ah, D: 3.24 m/s²
• Uncertainty: K = 1.5m/s²
• Rechargeable battery voltage: 18 V
• Battery capacity: 2.5 / 5 / 8 Ah
• Maximum torque
  • Hard: 158 Nm
  • Soft: 70 Nm
• Torque setting: 23 levels
• Idle speed
  • Gear/speed 1: 0 – 700 revolutions per minute
  • Gear/speed 2: 0 – 2500 revolutions per minute
• Idle stroke rate in gear 2: 0 – 4000 revolutions/minute
• Drill chuck capacity: 1.5 – 13 mm
• Maximum drill diameter
  • Wood: 89 mm
  • Steel: 13 mm
• Weight (without battery): 1.7 kg

Do you know – Li-Ion batteries:

• Do not have any memory effect
• Consist of cells with 3.6 V each
• After full charge they have a higher voltage than 3.6 V i.e. 5 cells each 3.6 V = 18 V – but after full charge a peak voltage of up to 20 V is possible
  Attention: For a longer lifetime of the battery please store it charged up to 50 to 80 % only
• Have an energy density which is twice as high as nickel cadmium batteries, for example
• Have a nominal voltage three times higher than a nickel metal hydride battery
• Require multiple complete charging cycles to reach full capacity
