3⁄4″ Twin Turbo impact wrench ∙ 4100 Nm
Loosening torque maximum: 4100 Nm ∙ 3/4 inch square ∙ solid ∙ Powerful twin hammer mechanism
Product information
- Application:
Long service life and high efficiency in industrial and automotive applications.
Compact design, optimised for work in confined spaces - Loosening torque maximum: 4100 Nm
- Exhaust air is guided through the handle downwards
- Reduced vibrations
- Easy handling
- Short design – only 184 mm
- Strongest HAZET impact wrench
- Removable handle, 360° adjustable
- HAZET Twin Turbo technology – high torques with compact design
- 8-blade air motor with 25% higher impact performance ensures maximum torque
- One-hand operation for right- and left-handed users
Variants
Technical Data
| Loosening torque maximum | 4100 Nm |
| Manual/impact operation |
|
| Tightening torque maximum | 2170 Nm |
| Output |
|
| Net weight | 4.5 kg |
| Striking mechanism (type) |
|
| Air requirement | 243.5 l/min |
| Forward and reverse |
|
| Recommended torque | 1890 Nm |
| Handle | |
| Hose diameter (recommended) | 13 mm |
| Vibration acceleration | 10.69 m/s2 |
| Sound pressure level | 99.5 dB(A) Lp A |
| Revolutions per minute | 5200 |
| Thread type air inlet |
|
| Air connection inlet |
|
| Loosening torque (maximum) determined with screw size M | 32 M |
| Coupler plug |
|
| Sound power level | 110.5 db(A) Lp W |
| Air requirement [l/sec] | 4.1 l/sec |
| Working pressure (bar) | 6.3 bar |
