1⁄2″ Impact ratchet extension ∙ 170 Nm
1. Manufacturer's recommended list price, dealer prices may vary – prices are subject to change and errors excepted.
1. Non-binding recommended promotional price from the manufacturer as part of the “Special Worldwide” campaign, for example, dealer prices may vary - prices subject to change and errors.
in stock
available again soon
out of stock
Product information
- Application:
For tightening screws that are difficult to reach - Reaction-free striking mechanism for high levels of safety at work and low-impact operation
- Compact design
- High torque – approx. 30 % above standard ratchets
- Speed – approx. 3× as high as standard ratchets
- Loosening torque maximum: 170 Nm (at least with an input torque of 675 Nm)
- Tightening torque maximum: 170 Nm
- Suitable for manual retightening with torques greater than 270 Nm
Application:
- Passenger car sector, e.g. work on the chassis, brakes or exhaust system
- Construction and metalwork, e.g. handling steel structures
- Agricultural and commercial vehicle sector, e.g. repairs on tractors, construction machinery and trailers
Recommended drive system:
- Compressed air: 1/2″ impact wrench 9012TT (2200 Nm)
- Rechargeable battery: 1/2″ cordless impact wrench 9512-950 (950 Nm)
Variants
Technical Data
| Loosening torque maximum | 170 Nm |
| Manual/impact operation | |
| Tightening torque maximum | 170 Nm |
| Output |
|
| Net weight | 1.26 kg |
| Hose diameter (recommended) | 10 mm |
| Dimension | 458 x 41 x 46 mm |
| Air connection inlet |
|
| Coupler plug |
|
| Working pressure (bar) | 6.3 bar |
