3⁄4″ Cordless impact wrench ∙ 2100 Nm
1. Manufacturer's recommended list price, dealer prices may vary – prices are subject to change and errors excepted.
1. Non-binding recommended promotional price from the manufacturer as part of the “Special Worldwide” campaign, for example, dealer prices may vary - prices subject to change and errors.
in stock
available again soon
out of stock
Product information
- Patented vibration damping protects the wrist and the battery locking element
- Cordless impact wrench ∙ 18 V
- Basic unit ∙ without battery ∙ without charger
- Auto stop function stops the machine as soon as the striking mechanism starts or stops working when it is released: avoids overtightening or loss of screws and nuts during operation
- Prevents overtightening, e.g. of small screws, by being able to set three different speed ranges (“Speed Command”)
- Forward/reverse with switch-on lock
- Electronic emergency brake
- LED battery capacity display on battery pack
- Compatible with all 18 V battery packs in the 9500 system
- LED light (5-stage) with persistence afterglow
- Infinite speed regulation
- 3 tightening torque levels
- Idle speed
Level 1: max.: 500 revolutions/minute
Level 2: max.: 1000 revolutions/minute
Level 3: max.: 1900 revolutions/minute - Idle speed impact rate: 0– 2350 revolutions/minute
- Ergonomic non-slip, rubberised grip
- Compact design
- Machine head made of die-cast aluminium - impact-resistant and durable
- Weight (without battery): 3.1 kg
- Electronic Management System (EMS) protects battery pack, extends service life and increases efficiency
- Vibration acceleration for screws ah: 17.4 m/s2
Uncertainty: K=1.5 m/s2 - Brushless DC motor (BLDC):
- Longer service life, less wear, no need to change the carbon brushes
- High efficiency and hence lower battery consumption – more compact motor enables smaller installation dimensions
- Maximum storage temperature: 50° C
- Charging temperature: 4 to 40° C
Do you know – Li-Ion batteries:
- Do not have any memory effect
- Consist of cells with 3.6 V each
- After full charge they have a higher voltage than 3.6 V i.e. 5 cells each 3.6 V = 18 V – but after full charge a peak voltage of up to 20 V is possible
Attention: For a longer lifetime of the battery please store it charged up to 50 to 80 % only - Have an energy density which is twice as high as nickel cadmium batteries, for example
- Have a nominal voltage three times higher than a nickel metal hydride battery
- Require multiple complete charging cycles to reach full capacity
Variants
Technical Data
| Battery voltage [V] | 18 V |
| Loosening torque maximum | 2100 Nm |
| Manual/impact operation | |
| Output |
|
| Rechargeable battery / battery replaceable | Ja |
| Dimension | 209 x 98 x 243 mm |
| ElektroG [Electrical and Electronic Equipment Act] – weight to be reported | 3.05 KG |
| Battery category under the German Electrical and Electronic Equipment Act (ElektroG) |
|
| ElektroG [Electrical and Electronic Equipment Act] device category / type of use |
|
| Operating temperature range | -10°C – 40°C |
| Batteries/Rechargeable batteries required for operation | Ja |
