¹⁄₂″ Cordless impact wrench ∙ 950 Nm

• Patented vibration damping protects the wrist and the battery locking element
• Cordless impact wrench ∙ 18 V
• Basic unit ∙ without battery ∙ without charger
• Auto stop function stops the machine as soon as the striking mechanism starts or stops working when it is released: avoids overtightening or loss of screws and nuts during operation
• Prevents overtightening, e.g. of small screws, by being able to set three different speed ranges (“Speed Command”)
• Forward/reverse with switch-on lock
• Electronic emergency brake
• LED battery capacity display on battery pack
• Compatible with all 18 V battery packs in the 9500 system
• Powerful impact mechanism for maximum performance enables the operation of stuck, e.g. rusted screw connections, even in extreme applications
• LED light with persistence afterglow
• 3 tightening torque levels
  Level 1: 150 Nm ∙ 0 – 1000 revolutions/minute
  Level 2: 200 Nm ∙ 0 – 2000 revolutions/minute
  Level 3: 750 Nm ∙ 0 – 2450 revolutions/minute
• Idle speed
  Level 1: 0 – 500 revolutions/minute
  Level 2: 0 – 1000 revolutions/minute
  Level 3: 0 – 2100 revolutions/minute
• Compact design
• Machine head made of die-cast aluminium - impact-resistant and durable
• Weight (without battery): 1.9 kg
• Brushless DC motor (BLDC):
  • Longer service life, less wear, no need to change the carbon brushes
  • High efficiency and hence lower battery consumption – more compact motor enables smaller installation dimensions
• Electronic Management System (EMS) protects battery pack, extends service life and increases efficiency
• Ergonomic non-slip, rubberised grip
• Charging temperature: 4 to 40° C
• Maximum storage temperature: 50° C
• Max. number of impacts: 2800 impacts/minute

Do you know – Li-Ion batteries:

• Do not have any memory effect
• Consist of cells with 3.6 V each
• After full charge they have a higher voltage than 3.6 V i.e. 5 cells each 3.6 V = 18 V – but after full charge a peak voltage of up to 20 V is possible
  Attention: For a longer lifetime of the battery please store it charged up to 50 to 80 % only
• Have an energy density which is twice as high as nickel cadmium batteries, for example
• Have a nominal voltage three times higher than a nickel metal hydride battery
• Require multiple complete charging cycles to reach full capacity
