Product information
- Plug connection for holding insert tools
- Accuracy ± 3% of the scale value (in direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool - Safety:
- Haptic (close-gap release)
- Audible (“click” sound)
- Designed for rough workshop use
- Wide range of applications for controlled screw tightening in tyre service, bicycle, passenger car and commercial vehicle applications as well as various applications in trade and industry
- Optimised sealing ring to protect against debris
- Handle with better grip for easier power transmission
- Adjustment aid with detent points for optimised operator guidance ensures safe and fast adjustment of the desired torque value by turning the handle
- Safe locking of the setting values by latching function on the rotary assembly
- Rotary assembly in triangular form prevents uncontrolled rolling
- Lock symbols indicate the respective locking status
- Can be attached to the cable loop through openings on the locking rotary assembly
- Easy-to-read, high-contrast scale
- Permanent readability due to laser marking on the scale bush
- With calibration certificate and serial number
- Delivery in sturdy Hexa plastic box
- Made in Germany
- No more turning back: Continuous long-term tests on the 5000 series and 6000 series of HAZET torque wrenches have demonstrated that turning them back to the smallest scale value is not required
SYSTEM 5200-3 CT Insert torque wrenches
10 – 200 Nm ∙ with insert square ∙ accuracy ± 3 %
Variants
Technical Data
Output |
|
Tolerance | 3 % |
Tightening torque min Nm | 40 Nm |
Head Width b | 30 mm |
Tightening torque max Nm | 200 Nm |
Head Thickness a | 23 mm |
Scale Graduation (Nm) | 1 Nm |
Standard |
|
Inside micrometre of the adjusting tool l2 | 38.5 mm |
Length | 484 mm |
Actuating force min.-max. kg | 8.9 – 46.6 |
Effective torque wrench length I1 mm | 422 mm |
