14 x 18 mm Torque wrench ∙ 20 – 120 Nm ∙ ±3%
Length: 395 mm ∙ 20 – 120 Nm ∙ 3 % ∙ 14 x 18 mm insert square ∙ hollow
1. Manufacturer's recommended list price, dealer prices may vary – prices are subject to change and errors excepted.
1. Non-binding recommended promotional price from the manufacturer as part of the “Special Worldwide” campaign, for example, dealer prices may vary - prices subject to change and errors.
in stock
available again soon
out of stock
Product information
- Plug connection for holding insert tools
- Accuracy ± 3 % of the scale value (in the direction of actuation)
Can be used for right-hand and left-hand threads by turning the insert tool - Safe:
- Haptic (close-gap release)
- Audible (“click” sound)
- Designed for rough workshop use
- Wide range of applications for controlled screw tightening in tyre service, bicycle, passenger car and commercial vehicle applications as well as various applications in trade and industry
- Optimised sealing ring to protect against debris
- Handle with better grip for easier power transmission
- Adjustment aid with detent points for optimised operator guidance ensures safe and fast adjustment of the desired torque value by turning the handle
- Safe locking of the setting values by latching function on the rotary assembly
- Rotary assembly in triangular form prevents tool from rolling away uncontrollably
- Lock symbols indicate the respective locking status
- Can be attached to the cable loop through openings on the locking rotary assembly
- Easy-to-read, high-contrast scale
- Permanent readability due to laser marking on the scale bush
- With calibration certificate and serial number
- Delivery in sturdy Hexa plastic box
- Made in Germany
Variants
Technical Data
| Output |
|
| Tolerance | 3 % |
| Tightening torque minimum | 20 Nm |
| Head Width b | 30 mm |
| Tightening torque maximum | 120 Nm |
| Head Thickness a | 23 mm |
| Scale Graduation (Nm) | 1 Nm |
| Standard |
|
| Inside micrometre of the adjusting tool l2 | 38.5 mm |
| Dimension | 395 mm |
| Actuating force min.-max. kg | 5.6 – 35.3 |
| Effective torque wrench length I1 mm | 322 mm |
